DVI Uncompressed Video Fiber Optic Transmission

DVI Uncompressed Video Fiber Optic Transmission

DVI
DVI+KVM
Product description: CJ3001D is a set of extender device of high-definition video transmission which use fiber optic, just need a single fiber will be able to transmit 1080p signal over long distances, it support audio tr
INQUIRY

CJ3001D is a set of extender device of high-definition video transmission which use fiber optic, just need a single fiber will be able to transmit 1080p signal over long distances, it support audio transmission. This product is ideal for large-screen display, conferencing systems and home entertainment and so on. The device has the ability of anti-interference, to ensure the stability of the signal.

Feature：
● Compliance with DVI1.0 standard
● Support DVI signal input or output
● HDCP1.2
● The Transmitter support the transmission of the DVI audio and the independent stereo
● The Receiver support the output of the DVI audio and the Independent stereo
● Support 1080p 60H, single mode fiber transmission up to 10 KM
● Real-time transmission of high-definition uncompressed digital DVI video signal, the video is clear and stable
● Built-in ESD protection circuitry, can effectively prevent electrostatic damage
● Site installation: easy, plug and play, no need to set
● Support serial unidirectional transmission, baud rate adaptive

Port Description

Transmitter	Function Description
DVI IN	DVI-D Input(support HDMI input)
Audio IN	Stereo audio input, when accessed to audio, DVI audio is not transmitted
DC/5V	Power input 5V2A
Fiber	Optical interface LC interface
Receiver	Function Description
OUTPUT	DVI Output(Support HDMI output)
Audio out	Stereo audio output, when inserted into the speakers, DVI no audio output
DC/5V	Power input 5V2A
Fiber	Optical interface LC interface

Specifications

Operating Temperature Range	-5 to +50°C
Operating humidity range	5 to 90 % RH (no condensation)
Input video signal	0.5-1.0 volts p-p
Input DDC signal	5 volts p-p (TTL)
Support Video Format	19201080@60Hz 19201080@50Hz 19201080@30Hz 19201080@25Hz 19201080@24Hz 1080I@60Hz 1080I@50Hz 1280720@60Hz 1280*720@50Hz
Audio output	Stereo
The maximum transmission distance	single mode single fiber 10KM
Optical interface	LC fiber optic interface
Optical fiber wavelength	1310nm FP
Input Power	DC 5V / 2A
Power Consumption	Transmitter 5W Receiver 5W
